XROTOR AM32 4-IN-1 G2 65A Drone ESC 30x30

$119.99

only left for same day shipping. Order now!
Model: 0102DT0229
XROTOR AM32 4-IN-1 G2 65A Drone ESC 30x30
32-bit microprocessors and the AM32 firmware for 3-6S for FPV racing. Large-size MOSFETs from Japan. it is very stable at low/greater voltage. Two ways for connecting the ESC to a FC: 1: Via soft cablesor 2: Via solder tabs. brand:HOBBYWING

Description

Generation 2 of what some consider the once best ESC. The Hobbywing XRotor G2 65A AM32 4-In-1 ESC delivers superior power and performance with support for 128k PWM output and Dshot1200. Built with imported MOSFETs and high-quality ceramic capacitors, this ESC is durable and strong enough to survive rough handling in any build.

Features:

  • High-performance 32-bit ARM F4 processor (120MHz) delivers fast processing and responsive ESC operation
  • Built with premium imported MOSFETs and ceramic capacitors for improved durability and electrical performance
  • 6-layer PCB with 3oz copper reduces heat, increases efficiency, and enhances reliability
  • Supports dynamic PWM frequency (48kHz–96kHz) for smoother and more precise throttle control
  • Integrated 4-in-1 65A ESC design in a compact form factor similar to a flight controller
  • Includes built-in 5V BEC and real-time voltage/current monitoring via onboard voltmeter
  • Compatible with DShot300/600 and PWM throttle signals for flexibility and strong anti-interference performance
  • Features soft-mount design for vibration dampening, protecting sensitive electronics during flight
  • Ships with AM32 firmware support, allowing advanced configuration and multiple update methods

Specifications:

  • MCU: Powered by a 32-bit ARM Cortex-M4 processor running at 120MHz
  • Firmware: Utilizes open-source AM32 firmware for flexible configuration and updates
  • Continuous Current: Rated for 65A sustained current per channel
  • Burst Current: Supports up to 80A peak (per channel) for short 10-second bursts
  • Input Voltage: Designed for 3–6S LiPo battery compatibility
  • Throttle Compatibility: Works with DShot300, DShot600, and standard PWM signals
  • PWM Range: Features adaptive PWM frequency from 48kHz to 96kHz for smoother performance
  • Telemetry: Includes onboard voltage and current sensing for real-time monitoring
  • Mounting Pattern: 30.5 × 30.5mm M3 holes with vibration-dampening (soft-mount) design
  • Weight: Approximately 15g excluding wires
  • BEC: 5V

More Information

Battery Voltage 3-6S
Manufacturer MAD
