KONKER 2267 FPV Racing Drone Motor 2150KV
MAD Motor KONKER 2267 2150KV — Built for 6S Freestyle FPV
The KONKER 2267 2150KV is MAD Motor's high-performance brushless motor engineered for 6S freestyle FPV drones. Delivering 2200g (2.2 kgf) of maximum thrust at just 26g of motor weight, it offers an exceptional power-to-weight ratio for aggressive freestyle flight, power loops, and high-speed cruising.
Key Features
- Optimized for 6S (22.2V) LiPo builds — maximum performance on high-voltage setups
- 2200g (2.2 kgf) Max Thrust — tested with 5.1×3.6 inch propellers
- Ultra-Lightweight at 26g — more thrust, less deadweight
- 240°C Copper Winding — handles sustained high-load flight without failure
- 180°C Magnet Temperature Resistance — anti-demagnetization under continuous stress
- Precision CNC Machined Bell — low vibration for smooth HD footage and flight feel
Specifications
| Specification | Value |
|---|---|
| Model | KONKER 2267 |
| KV Rating | 2150 KV |
| Stator Size | 22 × 6.7 mm |
| Motor Weight | 26g (without cable) |
| Recommended Voltage | 6S LiPo (22.2V) |
| Max Thrust | 2200g (2.2 kgf) |
| Recommended ESC | Pulsar 6S 60A 4in1 ESC |
| Recommended Propeller | Gemfan 51366 / 51466 Prop |
| Copper Winding Temp. Resistance | 240°C |
| Magnet Temp. Resistance | 180°C |
Best For
- 5-inch Freestyle FPV: Explosive power for flips, rolls, and power loops
- Long-Range FPV Builds: 2150KV keeps efficiency high on extended 6S flights
- Cinematic FPV: Low vibration output ideal for HD camera mounts
Frequently Asked Questions
Q: What propeller is recommended for the Konker 2267 2150KV?
A: We recommend 5.1×3.6 inch (5136) propellers for optimal thrust and efficiency on 6S builds. Max thrust of 2200g (2.2 kgf) is tested with this propeller.
Q: Is the Konker 2267 2150KV compatible with 4S batteries?
A: This motor is optimized for 6S (22.2V) setups. For 4S builds, we recommend choosing a higher KV variant from the Konker series.
Q: What is the motor weight?
A: The Konker 2267 weighs 26g without cable — one of the lightest options in its class for a 6S 2267 motor.
Q: What frame size is the Konker 2267 designed for?
A: It is designed for 6-inch freestyle frames (250–280mm wheelbase). Please verify the mounting pattern matches your frame before ordering.
Q: How does the Konker 2267 compare to the MAD Motor R-LOCK 2267?
A: Both share the 2267 stator size, but differ in KV tuning and application focus. The Konker 2267 targets freestyle and long-range 6S builds, while the R-LOCK 2267 is tuned for competitive racing. Contact us for a detailed comparison.
More Information
| Manufacturer | MAD |
|---|
